Performance & Powertrain

• Engine: Features a 567 cc ProStar single-cylinder, liquid-cooled, 4-stroke DOHC engine delivering approximately 44 HP. It runs on fuel injection and includes an electric starter. ATV.comPolaris Military
• Transmission: Uses Polaris’ Continuously Variable Transmission (CVT) with Hi/Low range, Reverse, and Park, powering the vehicle via a shaft drive. ATV.com
• Drivetrain: Equips On-Demand True AWD with selectable 2WD, AWD, and VersaTrac Turf Mode—ideal for tight turns without grass damage. ATV.comPolaris Military

Dimensions & Capability

• Ground Clearance: 10.5 inches, paired with 25-inch Carlisle tires. ATV.comPolaris Military
• Size & Weight:
  • Overall: 114″ L × 60″ W × 74″ H
  • Wheelbase: 79″
  • Dry Weight: ~1,070 lb ATV.comPolaris Military
• Payload & Cargo:
  • Payload Capacity: ~1,500 lb
  • Cargo Box: 36.5″ × 54″ × 11.5″ with 800 lb capacity
  • Fuel Capacity: 9 gallons ATV.comPolaris Military
• Towing Capacity: Up to 1,500 lb, supported by a standard 2″ receiver hitch. ATV.comPolaris Military

Chassis & Suspension

• Suspension:
  • Front: MacPherson strut, 9″ travel
  • Rear: Independent dual-A arm, 10″ travel Polaris MilitaryATV.com
• Brakes: Hydraulic disc brakes on all four wheels, with dual-bore front calipers and parking brake integrated into the transmission. Polaris MilitaryATV.com

Cabin & Usability

• Seating: Bench-style seat for 3 passengers. Polaris MilitaryATV.com
• Steering: Manual tilt steering column. Polaris MilitaryATV.com
• Instrumentation: A single analog dial with a 2″ LCD Rider Information Center that displays speed, RPM, trip data, fuel level, service codes, voltmeter, clock, hour meter, gear indicator, and seat belt reminder. Polaris Military
• Storage & Cargo: Under-seat storage, glove box, 2 cup holders, and support for Lock & Ride accessories. The cargo box uses a gas-assist dump mechanism for easy unloading. ATV.comPolaris MilitaryPolaris

Lighting & Build

• Lighting: Equipped with a 50W headlight and LED taillight. Polaris MilitaryATV.com
• Exterior: Durable steel frame with full-coverage front bumper and skid plates for lasting protection. ATV.com

Value Proposition (2023 Base Model)

• MSRP: Around $12,499 for the base trim. ATV.comtimeforwheels.com
• Positioning: Offers exceptional utility for its price, making it one of the most value-focused full-size UTVs in its class. Polaristimeforwheels.com

Owner Insights

Real-world user experiences offer valuable context:

“I bought the touring model… I have over 1000 miles on it with the original belt, engine and transmission… it’s been very reliable.” Reddit

“I fit great in the full-size 570, 2 inches to spare for my 6’6″ frame…” — great feedback on legroom comfort even for tall riders. Reddit

“I plowed for years with a sportsman 500ho… Just don’t be dumb with the throttle, use low and the belt will last.” — useful practical advice for using the Ranger 570 in rugged, utility-intensive roles like snow plowing. Reddit

Summary Table

This 2023 Polaris Ranger 570 Full-Size thrives as a no-frills, utility-minded UTV—packing dependable performance, strong payload/towing specs, and real-world versatility at a competitive price. It’s built for work, hauling, plowing, or general outdoor use,

2025 Polaris Ranger XP 1000 Premium—a rugged and refined utility side-by-side built to balance workhorse performance with rider comfort.

Performance & Powertrain

• Engine: Equipped with a 999 cc ProStar 4-stroke twin-cylinder DOHC engine, delivering around 82 HP.
• Drivetrain: High Performance On-Demand True AWD with selectable AWD, 2WD, and VersaTrac Turf Mode, enabling tight turns without damaging turf.
• Transmission: Gen 2 PVT CVT (H/L/N/R/P) with shaft drive, benefiting from a redesigned system that reduces shifting effort by up to 50%.Polaris
• Throttle Modes: Three-position throttle control—Performance, Standard, and Work—offer tailored responsiveness for varied tasks.
• Steering: Tilt steering with high-output electric power steering (EPS) for improved low-speed precision.

Dimensions & Capability

• Ground Clearance: 14 in, thanks to 29-inch Pro Armor X-Terrain tires (8-ply) on aluminum wheels.
• Suspension: Dual A-arm front and IRS rear with approximately 11 in of travel.
• Size & Weight:
  • Bed Box: 36.75″ × 54.25″ × 12.5″
  • Overall dimensions: 120″ L × 62.5″ W × 79″ H
  • Wheelbase: 81″
  • Payload: 1,500 lb
  • Towing: 2,500 lb
  • Dry weight: ~1,684 lb (764 kg); GVWR: 3,600 lb
  • Fuel capacity: 11.5 gal
  • Seating: 3-passenger bench

• Cargo & Utility:
  • Lock & Ride® cargo system
  • Gas-assist dump bed for effortless unloading


Lighting & Accessories

• Lights: Dual LED headlights (1,250 lm low beam / 2,300 lm high beam) and dual LED tail lights.
• Winch & Mounting:
  • Factory-installed Polaris HD 4,500-lb synthetic rope winch, complete with auto-stop and wireless remote.
  • Integrated front bumper supports winch, plow, and LED mounts.
• Electrical System: Polaris Pulse — includes six-position busbars both under the hood and on the roof, plus 12V and USB outlets, and a battery trickle-charging port.

Comfort & Interior

• Comfort Add-ons: Factory-installed poly sport roof, single-latch cab nets, and premium cut-and-sew seats with embroidered branding, back bolsters, and contoured upholstery.
• In-Cab Convenience:
  • Dual glove box storage, up to 8 cup holders
  • USB charging port
  • Tilt steering wheel for ergonomics
  • Seamless bench-style seats for smooth in/out transitionsPolarisir.polaris.comwheelerpowersports.com
• Instrumentation: Dual analog dials coupled with a 4″ LCD display providing speed, RPM, fuel, temp, trip, service codes, gear, hour meter, and customizable blue/red backlighting. Includes speed limiting in 2 mph increments.

Updates for 2025

• Styling & Handling:
  • Bold new front-end styling with updated bumper and grille for added durability
  • Standard fitment of larger 29″ tires for better clearance and ride comfortPolaris
• Utility Enhancements:
  • Factory-installed roof and HD winch now standard
  • Cab nets redesigned for single-latch ease of use
  • EPS and Gen 2 transmission have received efficiency and responsiveness upgradesPolarisir.polaris.com
• Accessory Readiness: New upper front bumper and reverse light harness provided; JBL audio upgrade kits available soon.Polaris

Pricing Insight

• MSRP: Ranger 1000 Premium starts at $17,999 USD, while the Crew variant starts at $19,999.
